Product Overview

The VUZ series check valves are used in any type of hydraulic circuit, with a safe, compact design suitable to any hydraulic application using non-corrosive liquids. The VU size range includes two different standard openings at 5 to 65 psi. The VU series can also be used as a pressure sequence valve by adjusting the internal spring loading to the required cracking point, according to the valve size.

  • Size range: 1/8” thru 2”
  • Port options: NPT, SAE
  • Standard SAE threads
  • Standard crack 5 psi and 65 psi; various crack pressures optional
  • Material: high strength carbon steel with zinc plating
  • Any type of hydraulic circuit
  • Any hydraulic application using non-corrosive liquids
